Perception PEDAL DRIVE - Pedal Drive Installation into Kayak; Pedal Drive Operations; Deploying the Pedal Drive

Installing the Perception Pedal Drive
1. Remove the tethered mount bolt (I) from the
mounting bracket (H).
2. Leave the quick key (K) in the closed position so
that it is bridging the mounting bracket (H).
3. Align the propeller (G) so that it is parallel with the
shaft (F) of the pedal drive unit.
4. Holding the pedal drive at an angle lower the
propeller end into the kayak scupper.
5. Align the mounting bracket (H) receiver hole (I)
with upper collar (E) receiver hole and insert the
mounting bolt (I). Secure the mounting bolt (I)
with the threaded knob (J).
OPERATING THE PERCEPTION PEDAL DRIVE
Deploying the Pedal Drive
1. Align the propeller (G) so that it is parallel with the
shaft (F) of the pedal drive unit.
2. Retract the quick key (K) and lower the pedal
  drivethroughtheturboapsofkayakuntilitisin
the vertical deployed position.
3. Replace the quick key (K). You are now ready to
pedal the unit.
Note: Ensure that your kayak is in a sufcient depth
of water to accommodate the full depth of the
deployed pedal drive (approx. 18”).
