ST01
ST-01/M (Master) section 1
ST-01/S (Slave) section 1
Section top cover 2
Glass swing panel 2
RC-panel with cable 1
Documentation set: Certificate and Operation manual 1
STD01
Section with top cover and mounting kit 1
Glass swing panel 2
RC-panel with cable 1
Certificate 1
Delivery set
Technical
specifications
Operating voltage 24 V
Consumption current 6.5 A
Power consumption 160 W
Throughput in single passage mode up to 60 persons / min
Passageway width
with ATG-300, AТG-300H swing panels 650 mm
with ATG-475 swing panels 1000 mm
Mean time to failure 5,000,000 passages
Mean lifetime 8 years
ST-01 weight with swing panels 188 kg
STD-01 weight with swing panels max. 118 kg
Overall ST-01 dimensions (without
including FP-01C, FP-01Q, FP-01A
front panels):*
with ATG-300 swing panels 1820х1050х1010 mm
with ATG-300H swing panels 1820х1050х1300 mm
with ATG-425 swing panels 1820х1300х1010 mm
with ATG-475 swing panels 1820х1400х1010 mm
with ATG-575 swing panels 1820х1600х1010 mm
* Overall dimensions when organizing multiple passage lanes using several STD-01
Ltotal = 920n + 117 0 m + 12 70 k + 130 (mm), being:
n – the number of installed pairs of ATG-300 and ATG-300H swing panels;
m – the number of installed pairs of ATG-425 swing panels;
k – the number of installed pairs of ATG-475 swing panels.
Connection
The slave section (side of the bidirectional section) is connected by its standard cables to the
Master section (side of the bidirectional section) of one passage lane. The master section
(side of the bidirectional section) is equipped with the ST-01.771 control board (located at the
bottom of the central section post behind the cover plate). All external connections are made
to the board contacts. Microcontrollers installed on the boards control the drives of the swing
panels, process signals from IR sensors, process external commands, and generate signals
about passages through the turnstile.
ST-01.770 control board contacts description by connectors
Connector Contact
Electrical
circuit
Designation
X1 (POWER)
1 24V
External power supply connection
2 GND
X2 (RC)
1 GND Common
2 UnlockA Direction A control input
3 Stop Control input – passage denial
4 UnlockB Direction B control input
5 LedA Indication output of direction A on the RC-panel
6 LedStop Indication output of passage denial on the RC-panel
7 LedB Indication output of direction B on the RC-panel
8 Sound RC-panel sound signal output
9 FireAlarm
Emergency passage opening control input
10 GND
