Perel FT120C User Manual

FT120C/FT130C
V. 05 – 23/04/2020 4 ©Velleman nv
4. Assembly
A
2x screw
C
1x handle
B
2x plain washer
A
1x handle
G
2x M12 nut
B
6x or 8x screw
H
2x wheel
C
6x or 8x spring washer
I
2x Ø 12 plain washer
D
6x or 8x plain washer
J
1x wheel shaft
E
1x feet
K
2x cotter pin
F
6x or 8x M5 nut
5. Installation
Install vertically on a flat, dry, stable and non-slippery surface.
Direct-fired heaters are intended for use in open outdoor areas or in well-ventilated indoor
spaces. For indoor use, provide permanent ventilation of at least 25 cm²/kW, equally
distributed between floor and high level, with a minimum of 250 cm².
FT120C
FT130C
600 cm²
800 cm²
Install the device in a normal upright position.
