3. General Guidelines
• Refer to the Velleman
®
Service and Quality Warranty on the last pages of this manual.
• All modifications of the device are forbidden for safety reasons. Damage caused by user
modifications to the device is not covered by the warranty.
• Only use the device for its intended purpose. Using the device in an unauthorised way will
void the warranty.
• Damage caused by disregard of certain guidelines in this manual is not covered by the
warranty and the dealer will not accept responsibility for any ensuing defects or problems.
• Nor Velleman nv nor its dealers can be held responsible for any damage (extraordinary,
incidental or indirect) – of any nature (financial, physical…) arising from the possession,
use or failure of this product.
• Keep this manual for future reference.
4. Overview
Refer to the illustrations on page 2 of this manual.
1
heater head
6
power cord
2
top pole
7
connection box
3
middle pole
8
link
4
bottom pole
9
anchor
5
base
10
cover ring
5. Assembly
1
Fix the bottom pole onto the base using the
appropriate screws and bolts.
Next, slide the cover ring onto the base.
