The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks is under license.
WARNING!
WARRANTY BECOMES VOID ONCE THE DEVICE CABINET HAS BEEN OPENED
OR ANY MODIFICATIONS OR ALTERATIONS TO THE ORIGINAL DEVICE HAVE
BEEN MADE.
NEVER OPEN THE DEVICE CASING. THE MANUFACTURER WILL NOT ACCEPT
ANY LIABILITY FOR DAMAGE RESULTING FROM IMPROPER HANDLING. THE
TYPE PLATE IS LOCATED ON THE BOTTOM OF THE DEVICE.
CONTROLS
Button overview
1. Info 8. Tuning / Seek / Select / Phone control
2. Menu 9. Preset + / Skip forward
3. Source 10. Preset / Play / Pause
4. Power 11. Alarm
5. Preset - / Skip backward 12. Forward
6. Volume / EQ control 13. Back
7. LCD Display
Top view
14. Metal handle 16. Top cover
15. Telescopic antenna
(Only required for DAB and FM band)
5 9
6 7 8
1
2
3
4
13
12
11
10
14
15
16
GB
