ASSEMBLY INSTRUCTIONS
Carefully unpack and spread out all parts in a large uncluttered area. Familiarize yourself with all parts and compare them
to the drawing below to make sure none are missing.
Read all assembly instructions before beginning.
PARTS LIST
# Description Qty. # Description Qty.
1 Handle 2 9 3/4” Bolt 8
2 Shelf 2 10 Large washer 8
3 1-1/2” Bolt 8 11 14mm Hex Nut 8
4 Small washer 8 12 Key 2
5 10mm Hex Nut 8 13 Drawer back cover 1
6 Crossbar 2 14 Locking Swivel Caster 2
7 Drawer 1 15 Swivel Caster 2
8 Side bracket with drawer rail 2 16 Caster Holder 4
Tools Required: (not included)
10mm wrench or socket
14mm wrench or socket
Rubber mallet
1. Slide a handle (1) through the holes on one end
of the shelf (2).
2. Line up the holes nearest the bend in the handle
with the holes on the side of the shelf.
3. Insert bolts (3) through the shelf and the handle
and secure with a washer (4) and hex nut (5).
