3
PACKAGING CONTENTS
Note: no tools are required for assembly, but inspect components for proper t and alignment before
assembling. Tighten any loose fasteners. Do not use if any parts are damaged or missing. Contact
manufacturer for customer service.
ASSEMBLY INSTRUCTIONS
Seat Cushion with
Lifting Lever
Cylinder
Base
Step 1
2. Carefully position the Seat assembly over
the center rod in the Pneumatic Cylinder and
press down.
Step 2
Step 3
1. Place base on solid surface and insert the
wider end of the Pneumatic Cylinder into the
opening in the center of the base.
3. Firmly press down on the seat to ensure all three
pieces have properly seated and t together tightly.
You should now be able to lift the seat up by the cush-
ion without it coming off of the Pneumatic Cylinder.
If the seat comes off, repeat steps 2 and 3.
PRESS
16 in. / 41cm
26 in / 66 cm
32 in / 81 cm
4 in. / 10 cm
Press seat lever
to raise and
lower seat.
