Perlesmith PSTVS18 - Page 4

(M-A) x4
M6x16mm
Bolt
(M-B) x4
M6x35mm
Bolt
(M-C) x4
M8x25mm
Bolt
(M-D) x4
M8x50mm
Bolt
(M-E) x4
M8x65mm
Bolt
P3
(M-H) x8
L5mm
Spacer
(M-I) x8
L10mm
Spacer
Note: The bolts and spacers are shown in accordance with the actual size
Supplied Part and Hardware for Step 3
Supplied Parts and Hardware for Step 4
x2
TV Bracket
06
(M-G) x4
D8x18x1.5
Washer
(H) x1
5/32in. (4mm)
Allen Key
(E) x8
M6x12mm
Bolt
Note: The bolt is shown
in accordance with the
actual size
(M-F) x4
Washer
x1
TV Plate
Connector
04
x2
TV Plate
05
