Speaker
(not included)
TightenTighten
Note: The speaker must be installed
on the middle of the speaker bracket.
360 Degree All-round Tilt Adjustment
If needed, the speaker angle can be adjusted.
1. Remove the speaker from the stand.
2. Slightly loosen the bolt [E].
3. Tilt the speaker bracket [03] to desired angle.
4. Tighten the bolt [E] to secure the speaker bracket
in place.
E
03
01 02 03 04 05
06 07 08 09 10
