Perlick BS108 User Manual

Perlick is committed to continuous improvement. Therefore, we reserve the right to change specications without prior notice
6
Form No.Z2278
Rev. 10.04.10
GENERAL INFORMATION – Custom Back Bar Cabinets
MODELS BS60/BR48 BS84/BR72 BS108/BR96
CONDENSING UNITS (BS ONLY)
Condensing unit 115 volt, 60 hz.
C22647 C22646 C22646
Condensing Unit
515301063 515301062 515301062
Compressor
513200314 513200003 513200003
Condensor Fan Motor Assembly
515315009 515315009 515315009
Condenser Coil
15352019 15352019 15352019
Terminal Board
519100088 519100088 519100088
Overload Protector
US-PB10HBX1 US-PB10HBX1 US-PB12HBX1
Relay
US-PB10HBX1 US-PB12HBX1 US-PB12HBX1
Capacitor
US-PB10HBX1 US-PB12HBX1 US-PB12HBX1
Self Contained (BS) complete
65555-1 65555-2 65555-2
Remote (BR) complete
65555-1R 65555-2R 65555-2R
Evaporator Coil (BS) & (BR)
C17511-1EP C17511-2EP C17511-2EP
Liquid & Suction Line (BS)
65084 65085 65085
Fan Blade
57699 57699 57699
Evaporator Fan Motor
C15239A C15239A C15239A
Evaporator Fan Guard
65557 65557 65557
Temperature Control
61283 61283 61283
Bulb Clamp
C6634 C6634 C6634
Wire Harness, Compressor Bottom
65560 65560 65560
Wire Harness, Evaporator
65561 65561 65561
Wire Harness, Light jumper
65538 65539 65539
Wire Harness, Mullion Heater
65571 65572 65573
Light Bulb
63821 63821 63821
Light Bulb Guard
65525 65525 65525
Light Socket
63484 63484 63484
Light Switch
65535 65535 65535
Lock
63762 63762 63762
Spacer, Lock
63761-1 63761-1 63761-1
Lock Rail
65432-24SS or 65432-24 65432-24SS or 65432-24 65432-24SS or 65432-24
Grille Rail
65432-12SS or 65432-12 65432-12SS or 65432-12 65432-12SS or 65432-12
Condensate Pan
65565-1 65565-1 65565-1
Condensing Housing End Panel
66215-1SS 66215-1SS 66215-1SS
Grille
RG-NL2 RG-NL2 RG-NL2
Condenser Housing Back
65435-12SS 65435-12SS 65435-12SS
Evaporator, Liquid & Suction Line Cover
65576-1L 65576-2L 65576-3L
Evaporator Pan
65526-1DB 65526-2DB 65526-2DB
Door Sill
65500-1 65500-1 65500-1
Door Handle
Several Options - Contact Factory
Door Gasket
66237-4 66237-4 66237-4
Cabinet Hinge Group Left
66264L 66264L 66264L
Cabinet Hinge Group Right
66264R 66264R 66264R
Hinge Pin
63679-1 63679-1 63679-1
End Shelf Kit (std. at)
57928 57928 57928
Center Shelf Kit (std. at)
N/A 57929 57929
Left or Right End Shelf (std. at)
62307-2 62307-2 62307-2
Center Shelf (std. at)
N/A 62308-2 62308-2
Plaster Strip
C19271-1 C19271-1 C19271-1
Shelf Clips (bag of 12)
63019-3 63019-3 63019-3
*Replacement Door
RND-NL2 RND-NL2 RND-NL2
*Contact Perlick Milwaukee for complete door replacement. Cabinet serial no. required.
