Perlick HP24FS - Page 6

6
Operation & Installation Manual
Signature Series (HP24 and HP48 models)
HP48 Models
25 7/16" Values may change
due to custom pull
with a wood overlay door.
10 13/16" Max.
product ht.
6 3/16"
6 3/16"
9 3/16" Max.
product ht.
17 1/4"
17 1/4"
12 1/4"
50" Area in which
electrical outlet must be located.
25 7/16" Values may change
due to custom pull
with a wood overlay door.
6 3/16"
8 3/8"
10 13/16" Max.
product ht.
9 3/16" Max.
product ht.
5 9/16" Max.
product ht.
3 3/16" 6 3/4" 10 1/2"
17 1/4"
* Leg leveler can add
3/4" to these dimensions
when fully extended.
J:\Dwg\95000\95006.slddrw
SCALE: 1:12
MILWAUKEE, WI 53223
PERLICK CORPORATION
NOT TO BE COPIED OR USED DETRIMENTAL TO OUR INTERESTS
DR.:
PRINTED
DATE:
4/24/2012
95006
4/24/2012JMP
PROPERTY OF THE PERLICK CORP.
SHEET 2 OF 3
Signature Series HP48 Models
*34 5/16"
*4"
47 7/8"
24"
(with
1/16" tolerance)
Power cord 81/4" off floor.*
(Top & Bottom)
17 13/16"
Inside drawer
17 11/16"
1 3/8"
17 13/16"
Inside drawer
(Top & Bottom)
24"
(with
1/16" tolerance)
1 1/4" Min.
clearance from
a corner to
acheive 90
door swing.
24 15/16"
Min. clearance
for door swing.
44"
20 5/8"
6 3/8"
11 3/4"
22"
12 1/4"
50" Area in which
electrical outlet must be located.
24 7/8"
26 9/16"
1 11/16"
2 1/4" Lowest
shelf location.
2" Shelf
adjustability.
20 11/16"
5 1/4"
19 5/8"
1 11/16"
26 9/16" 19 7/8" 19 7/8"
6 3/16" Lowest
shelf location.
2" Shelf
adjustability.
5 1/4"
26 9/16"
19 5/8"
1 11/16"
6 3/8" 11 3/4"
18 1/8"
Power cord 81/4" off floor.*
90° Swing
required for
pullout shelf
clearance.
(with 1/16" tolerance)
24"
25 7/16" Values may change
due to custom pull
with a wood overlay door.
* Leg leveler can add
3/4" to these dimensions
when fully extended.
Signature Series HP48 Models
*34 5/16"
*4"
47 7/8"
J:\Dwg\95000\95006.slddrw
SCALE: 1:12
MILWAUKEE, WI 53223
PERLICK CORPORATION
NOT TO BE COPIED OR USED DETRIMENTAL TO OUR INTERESTS
DR.:
PRINTED
DATE:
4/24/2012
95006
4/24/2012JMP
PROPERTY OF THE PERLICK CORP.
SHEET 1 OF 3
(with 1/16" tolerance)
24"
25 7/16" Values may change
due to custom pull
with a wood overlay door.
All Door (Figure 3)/All Drawer
Models (Figure 4)
