2.4 Hide the 5-point seat belt
1. Press the central adjuster (04) down and pull the shoulder belts (32) towards you, (DO NOT pull on the shoulder
pads (06)) release the 5-point harness as far as it will go.
2. Press the red button (19) to open the 5-point seat belt.
3. Pull the adjusting handle (09) upwards, whilst pushing the headrest (08) downwards to the suitable position.
4. Take o the seat cushion. (45)
5. Unbutton both sides.
6. Open the hook and loop at the shoulder belts,and remove the shoulder belts. (32)
7. Open the cloth cover of headrest, plug the buckle latches (20) on both sides intothe shoulder pads (08)
respectively.
8. Tuck the shoulder strap and seat belt together behind the perforated plastic plate.
9. Remove the 5-point seat belt buckle (14) from the crotch pad. (41)
10. Take the 5-point seat belt through the house.
11. Place the 5-point seat belt buckle (14) into the crotch pad. (41)
12. Rotating 5-point seat belt buckle and crotch pad so that they face down (25) and put them in the the groove,and
put EPE on top of the 5-point seat belt buckle.
13. Put down headrest‘s cloth cover.
14. 5-point seat belt hiding is complete.
15. Button up the cloth cover.
25
26
27
28
29
08
15
16
17
18
19
20
21
22
23
25
26
27
29
28
2.0 Vorbereitende Arbeiten und Funktionen
2.0 Preparatory Work and Functions
24
Vertiefung / groove
EPE
