-4-
Press light and baffle
tightly against window
Tighten the nuts securing
the mounting brackets
BAFFLE ADJUSTING SCREWS
(qty=5)
Mounting (CONT'D)
11. Loosen the five Baffle
Adjusting Screws located
on the bottom of the
Starburst Phantom
®
.
12. Slide the baffle forward
until it satisfactorily
blocks any reflected
light.
13 Tighten the Baffle
Adjusting Screws to
secure the baffle in
place .
CAUTION: Take extreme caution not to over tighten the screws!!! Over
tightening of the screws can strip the holes.
14. Make any final adjustments necessary.
