2.1.2 315MHzWirelessOccupancySensing
TheAirwavetransceiverisfullycompatiblewithPhilipsLedaliteorotherwirelessoccupancysensorsthatoperateatafrequencyof315MHzandareembeddedwiththeEnOcean
protocol.Thesesensorstypicallyuseinfra-red(PIR)technologysuitableforwallorceilingmountlocationswheretherangeofmotiondetectionrequiredislimited.Mostavailable
wirelessoccupancysensorsarenotcompletelyself-powered,butareinfacthybriddevicesthatincorporatesolarenergyharvestersANDrelyontheuseofbatteriestoremain
operationalformorethanafewhoursand/orautomaticallyturnONwhenmotionisdetected.Wirelessoccupancysensorscanbeusefulenergysavingstoolswhenappliedcorrectly,
howeverusinganAirwavekineticallypoweredwirelessswitchinconjunctionwithwirelessoccupancydeviceisarecommendedbestpracticeforfail-safereliability.
2.1.3 DimtoOFF
AllvacancysignalssenttotheAirwavetransceiverfromanoccupancyormotiondetectiondeviceautomaticallyinitiateaslow-fadedimmingofluminaires,eventuallyshuttingoffthe
fixtures when the space is unoccupied. This smooth transition means environments remain dynamic and efficient, while also being sensitive to the people who inhabit them.
2.1.4 Auto-ON
TheAirwaveTransceiverissettoAuto-ONwhenanoccupancysignalisreceived.TheAuto-ONOccupancymodecanbemanuallyoverriddenbyturningthexturesoffusinga
switchtoallowlightstostayoffduringanA/Vpresentation.TheTransceiverwillautomaticallyreverttoAuto-ONOccupancyoncetheoccupantshavelefttheroom.Theoverridecan
alsobemanuallyrevertedbymanuallyswitchingthelightsbackonagainatanytime.
2.2 Transceiver Specifications
InputVoltage 120,277,or347VAC
RelayLoad 20Aballastload(120/277VAC),15Aballastload(347VAC)zerocrossing
DimmingControl 0-10Vcurrentsinkonly,upto50ballasts
LowVoltageOutput 24VDC,50mA
OccupancyControlInput Activehigh
Dimensions 5.3”x5.3”x2.4”(99mmx99mmx61mm)
OperatingTemperature -10°to+45°C
RegulatorySafety UL508,CSAC22.2No.14-05,UL2043PlenumRated
CCEA Surfacemountinstalloutsideairhandlingspace(Chicagoonly)
Wireless Frequency 315 MHz
TransmissionPower max.10mWEIRP
TransmissionRange 100ftindoor(30.5m)
WirelessTechnology EnOcean
MaximumTransmitterIDs Uptocombinationof30switches/wirelessoccupancysensorsor29switches/Wirelessoccupancysensorsand1photosensor
RegulatoryRadio FCC,IC
