Philips Ledalite Airwave - 4.0 Solar Powered Wireless Occupancy Sensor

Product Manual
© Philips Ledalite 2011Page 6
4.0 Solar Powered Wireless Occupancy Sensor
TheAirwaveoccupancysensorisabattery-freedevicewhichoperatesonsolarenergyharvestedbyintegralphotovoltaiccells.Thisenablesthedevicetobeplacedanywhereinthespaceand
movedatanytimeaftertheinitialinstallation.ThesensorusesPassiveInfrared(PIR)detectioncircuitryandwirelesstransmissiontosendanoccupancyorvacancysignaltotheAirwavetransceiver,
which responds by turning the lights on or gradually dimming the lights to off.
TheAirwaveoccupancysensorcandetectmotioninuptoa30footdiameterwhenplacedon8to12footceiling.TheoptimalplacementforPIRoccupancysensorsisdirectlyabovetheareawith
themostmotionandwherethemotionisnotshadowedbyline-of-sightobstacles.
Thewirelessoccupancysensortimedelayissetinthetransceivermemoryat15minutes,butcanbeuseradjustedto30secondsor5,10,15,20,or25minutes.(SeetheAirwaveProgramming
Guideforinstructionsonsettingtheoccupancytimedelay.)
ThetimedelayparameterintheTransceivermustbesetafterthewirelessoccupancysensorislinked.Thetimedelayprogrammingsettingisthe“TimedSwitch”delaytimeuntilanoccupancy
sensorisattached(wiredorwirelessly).
AnAirwavewallswitchwillallowmanualon/offcontrolofthelightsregardlessofwhethertheTransceiverissetinmanual-Onorauto-Onoccupancymode.
ForconferenceroomapplicationswherethelightsneedtobeoffduringanA/Vpresentation,thelightswillremainoffafteramanual-OfffromanAirwaveswitchuntiltheroombecomes
unoccupiedorthelightsaremanuallyswitchedbackon.AfterthispointtheoccupancysensorandTransceiverwillreturntonormalon/offcontrolofthelighting.
4.2 Specifications
PowerSource Miniaturephotovoltaiccell-nobatteriesrequired
Minimumcontinuousoperatinglight 3footcandles(30lux)
Minimumchargetimefromdischargestate 1minuteat3footcandles(±30lux)
Timetofullycharge 8hoursat20footcandles(±200lux)
Operatinglifeafterfullycharged min.60hoursat0footcandles(0lux),includingAuto-Onapplications
Optionalbatterylife 10years
Fieldofview 360°
Dimensions 4.8”diameter(122mm),1.5”height(38mm)
Mounting Surfacemountviascrews,tape,glue,etc
OperatingTemperature -25°to+65°C
Wireless Frequency 315 MHz
TransmissionRange 100ftindoor(30.5m)
TransmissionInterval 2minutes(rstoccupancydetectionsendsanimmediatetransmission)
WirelessTechnology EnOcean
RegulatoryRadio FCC,IC
LinkButton
