17” CDT Color Monitor 107S7
83
---DBC test required and refer to TYE-M0002.
• Transportation test specification for all regions except China/India, refer to UAN-D1534/01
Sequential tests:
1. Vibration test
2. Drop test
3. Single package resonance test (optional)
4. Compression test
5. Stacking test (optional)
• Transportation test specification for China/India, refer to UAN-D1534/02
Sequential tests:
1. Vibration test
2. Bump test
3. Drop test
4. Multiple drop tests (after vibration)
5. Cold drop test when applicable (after vibration)
6. Compression test
7. Stacking test (optional)
5.16 Pallet / Container loading
•
Air shipment - tbc
• Sea container 20'(pallet/slip sheet) - 300 sets with pallet
310 sets without pallet
•
Sea container 40'(pallet/slip sheet) - 630 sets with pallet
635 sets without pallet
•
Sea container 40' High Cube (pallet/slip sheet) - 756 sets with slip sheet
•
Truck shipment for China - 400 sets
Table 5.16.1. Air shipment container loading
TBC
Table 5.16.2. Sea shipment container loading for China & India
Container size
40’ 20’ 40’ High Cube PWHC 45'
Quantity
W/ Pallet W/ W/ Pallet W/ W/ Pallet W/ SLIP W/ Pallet W/
