Product Number 109S40
CRT
• Size (inch/cm) 19"/46 cm (18.0" VIS)
• Deflection Angle (degrees) 90°
• Dot Pitch 0.27 mm
• Horizontal Pitch 0.23 mm
-Tube Type Invar Shadow mask, Flat Square, High Contrast,
Anti-Glare, Anti-Static, Anti-Reflection,
Light Transmission 46%
• Phosphor P22
• Recom. Display Area (mm) 355 x 265 mm
• Recom. Display Area (inch) 14.0" x 10.4"
• Max. Display Area (mm) 360 x 270 mm
• Max. Display Area (inch) 14.4" x 10.8"
Scanning
• Horizontal Scanning 30 - 92kHz
•Vertical Scanning 50 - 160Hz
Video
• Video Dot Rate 158MHz
• Input Impedance
-Video 75Ω
-Sync 2.2kΩ
• Input Signal Levels 0.7 Vp-p
• Sync Input Signal Separate Sync
Composite Sync
• Sync Polarities Positive and Negative
White Color Temperature
Chromaticity CIE Coordinates:
• at 9300 K: x=0.283, y=0.297
• at 6500 K: x=0.313, y=0.329
Resolution and Preset Modes
• Max. Resolution 1920 x 1440
• Recom. Resolution 1280 x 1024
• 16 User Definable Modes
• 31 Factory Preset Modes:
Plug and Play Compatibility
• Display Data Channel DDC 2B (VESA)
• Microsoft®,Windows® 95/98/Me 2000/NT/XP PC2001 compatible
• sRGB
Power Management
Complies with EPA Energy Star, NUTEK Specifications
• Operation (typ.) 83 W
• Suspend/Stand-By Mode (typ.) < 2 W
• Off Mode/Deep Sleep < 2 W
Low-Emission Characteristics
• Complies with MPR-II and TCO '99 Specifications
Monitor Controls and Functions
• Main 5-Button OSD
Brightness +/- Direct Access
Contrast+/- Direct Access
• On Screen Display Language (English, Spanish, French, German, Italian,
Chinese, Portuguese, Korean), Zoom, Horiz/Vert
Position and Size, Pincushion, Balanced,Trapezoid,
Parallelogram, Color, Reset, Degauss, Moire, Serial
Number, Resolution, Frequency, sRGB
• LightFrame™3 For improving the picture display of multimedia
content such as photos, videos and games.Will
boost brightness and sharpness performance on
user selected areas/windows on the screen.With
automatic detection of graphical content in Internet
Explorer for the web browsing. Can process up to
16 images simultaneously. One-button full screen
mode. Advanced user adjustments via Windows
control panel. Easy to use control software for
Windows 98, Me. XP and 2000. Software in English,
French, German, Spanish, Italian, Portuguese, Dutch,
Chinese and Korean.
Connections and Cables
• Connections
-Video 15-pin D-Sub Input
• Cables D-Sub Video (fixed) and Power Cord
Regulatory Approvals
• TCO '99 • MPR-II Low Emission
• TüV/GS,TüV-Ergo,TüV/9241-3 • FCC-B, UL, CSA, DHHS
• SEMKO, Poland-B Sign, C-Tick • CE, BCIQ, PSB
• NUTEK, Energy Star
Physical Specifications
• UPC Code 109S40 0 37849 92898 1
• Unit Dimensions (WxHxD) 17.3" x 17.6" x 17.3"
440 x 447 x 441 mm (incl base)
17.3" x 15.7" x 17.3"
440 x 399 x 441 mm (excl base)
• Unit Weight 43.3 lbs./19.4 kg
• Carton Dimensions (WxHxD) 21.90" x 21.30" x 20.50"
556 x 541 x 520 mm
• Carton Weight 49 lbs./22.23 kg
• Power Supply 90 - 264 VAC, 50/60Hz
•Temperature (operating) 0°C to +40°C/32° to 104°F
•Temperature (storage) -25°C to +65°C/ -13° to 149°F
• Relative Humidity 5% to 95%
• MTBF (excl. CRT) > 75,000 H
Optional Accessories
• USB Hub Option Type PCUH411
• Multimedia Base Option Type 6G3B11
Carton contains: 109S Monitor, power cord, and user’s manual on CD.
INTERNET ADDRESS: http://www.philipsusa.com
TECHNICAL SUPPORT: (877) 835-1838 (USA)
(402) 536-4171 (outside USA)
Specifications subject to change without notice.
Printed in the U.S.A., ©2003 Philips Consumer Electronics Co.A Division of Philips Electronics North America
Corp. As an Energy Star partner, Philips has determined that this product meets the Energy Star guidelines for
energy efficiency. Microsoft and Windows are registered trademarks of Microsoft Corporation MacOS is a regis-
tered trademark of Apple Computer, Inc.All trademarks acknowledged. Copyright 2001 Koninklijke Philips
Electronics N.V.
CCM-110-01/03
Literature Order Number: 109S40
Resolution H.freq V.freq
640 x 480 31.5(kHz) 60(Hz)
640 x 480 37.9(kHz) 72(Hz)
640 x 480 37.5(kHz) 75(Hz)
640 x 480 43.3(kHz) 85(Hz)
640 x 480 50.6(kHz) 100(Hz)
720 x 400 31.5(kHz) 70(Hz)
720 x 400 37.9(kHz) 85(Hz)
800 x 600 37.9(kHz) 60(Hz)
800 x 600 48.1(kHz) 72(Hz)
800 x 600 46.9(kHz) 75(Hz)
800 x 600 53.7(kHz) 85(Hz)
800 x 600 63.9(kHz) 100(Hz)
832 x 624 49.7(kHz) 75(Hz)
1024 x 768 48.4(kHz) 60(Hz)
1024 x 768 56.5(kHz) 70(Hz)
1024 x 768 60.0(kHz) 75(Hz)
Resolution H.freq V.freq
1024 x 768 68.7(kHz) 85(Hz)
1152 x 864 67.5(kHz) 75(Hz)
1152 x 870 68.7(kHz) 75(Hz)
1152 x 900 71.8(kHz) 76(Hz)
1280 x 960 60.0(kHz) 60(Hz)
1280 x 960 85.9(kHz) 85(Hz)
1280 x 1024 64.0(kHz) 60(Hz)
1280 x 1024 80.0(kHz) 75(Hz)
1280 x 1024 91.1(kHz) 85(Hz)
1600 x 1200 75.0(kHz) 60(Hz)
1600 x 1200 81.3(kHz) 65(Hz)
1600 x 1200 87.5(kHz) 70(Hz)
1792 x 1344 83.6(kHz) 60(Hz)
1856 x 1392 86.3(kHz) 60(Hz)
1920 x 1440 90.0(kHz) 60(Hz)
109S4
109S4
Technical Specifications
