7. Circuit Diagrams and PWB Layouts
Waveform Diagram
TPT1.1A LA
1.BDDCWP_PC(U1102 Pin 7)
2. +5V_Tuner(U1201 Pin 3)
3. CPU_RESET(U4103 Pin 2)
4. E_PAGE(U4101 Pin 7)
5. 10MHz(X4101 Pin 1)
6. 28.322MHz(X4201 Pin 1)
7. RESET_H(R4301)
8. PX_VDDM(C4307)
9. DDCWP_HDMI(U5101 Pin 7)
10. HDMI1_5V(U5101 Pin 8)
11. HDMI2_5V(U5102 Pin 8)
12. +1.5V(C5124)
13. 14.3181MHz(X5201 Pin 1)
14. ADC_RESET(R5201)
15. +5V_MSP(C6203)
16. 18.432MHz(X6201 Pin 1)
17. RESET(U6202 Pin 16)
18. SOUND_EN(U6301 pin 44)
19. SOUND_MUTE(U6301 Pin 45)
20. FAULT(U6301 Pin 46)
21. +24V_AMP(C6365)
22. POWER_ON(R7126)
23. LED_R(R7119)
24. LED_G(R7120)
