28 English
Wall mount
Printing instructions:
Print this page in scale 100 % and use the template to accurately mark the
position of the holes for the screws on the wall.
General information
Rechargeable Li-ion battery (2600mAh)
FHSS frequency band 2.4GHz.
Maximum radio-frequency power: <=20dBm
Supply unit:
Model: ASSA105E-050100 (EU plug) or
ASSA105B-050100 (UK plug)
Input: 100-240V 50/60Hz ~0.35A
Output: 5.0V 1.0A, 5.0W
Average active eciency: >=73.62%
No-load power consumption (W): 0.1W
