Philips AZ 385 - Performance, Safety, and Environment; Power Supply and Consumption

1-2
TECHNICAL SPECIFICATION
SET SPECIFICATION
VER 1
CD/MP3/FM/USB
AZ385/05/12
/
96
Prepared: Supers: 10 Sh. 190 4A
KT
Check:
DATE: © PHILIPS Electonics Hong Kong Ltd., BU-PORTABLE AUDIO
REMARKS :
General description:
1
LIFETIME : 5 YEARS (ACC. TO UAN-D1611)
2
PERFORMANCE CLASSES :
TUNER
SUPPLY,
AMPLIFIER
SPEAKER
BOXES
RECORDER CLOCK CD DCC TELEPHONE
REC.
PLAYER
I x x 3
II x 4
III 5
SAFETY REQUIREMENTS:
EN 60065 (IEC 65) CE ,
6
RADIATION, IMMUNITY REQUIREMENTS: (EMC)
EN55013, .EN55020 , (Version 05/12/61 approbation CB only )
EN61000-3-2:2006 EN61000-3-3:1995 (Version /61 approbation CB only )
7
CLIMATIC REQUIREMENTS: (acc. to UAN-D1590)
All climates: -10 C till +50 C (Functional); Set has to be pre-conditioned for 2 hour, except CD function 8
For all measurements: 25 C 9
POWER SUPPLY:
reffuB pukcaB / noitarepo ).txe ro .tni( CD noitarepo )CA( SNIAM
Voltage selection:
See table below
Battery type: R14, UM2, C-cell x 6; nom.: 9V
minimum operating voltage : 5V for CD / Tape
3.3V for TU
10
Selection:
See table below
Lifetime: CD 10 hours, TU 20 hours,
(R14 ‰˝ı alkaline batteries)
11
Frequency:
See table below
External DC: No 12
POWER CONSUMPTION:
Power off mode: 5W typ. Standby: <0.5W (power off mode) 13
Maximum: 15 W 41 :mumixaM
General:
Q and R according to production division rules : Q < 1% (Major), Q < 4% (Minor)
< R :ot gnidrocca derusaeM
3% (CE52)
NOITABORPPA :SNOISREV DEVIRED
Version
AC Voltage/
Frequency on
typeplate
Safety
Tolerance
Tuner
/05
UK
230VAC
50HZ
+/-10% FM,
230VAC
50HZ
/12
Europe
+/-10%
FM,
/61
Korea
220VAC
60HZ
+/-10% FM
15
