1-4
TECHNICAL SPECIFICATION
SUPPLY, AF-AMPLIFIER & LOUDSPEAKER (Boxes) PART:
TECHNICAL description:
Power supply Tone Control AF-Amplifier Loudspeaker
Active
components
MIX3004 1
Passive
components
2 X 8:, 1W
3
4
GENERAL part:
Aux in jack type Ø 3.5mm 5
Loudspeaker filter, high pass None 6
Loudspeaker filter, low pass None 7
Power stage protection Temperature – YES; Short circuit – YES 8
Public address No 9
INDICATORS:
Output power or VU-meter No 11
Frequency response No 12
Low power (battery) No 13
14
ELECTRICAL DATA:
TONE/EQUALIZER/DBB
DSC Balance control No 15
Mechanical noise (ISO 1996) 16
Noise overall (ISO) 17
Channel difference at -46dB Type: < 3 dB 18
Hum (vol.max.-20dB to vol.min.) Limit: 2mV 19
Residual noise(volume min) Limit: 2mV 20
DBB on (Vol.max.-20dB): 100Hz, +6dB
(r2dB) w.r.t. 1kHz at DBB on
DBB has no dynamic, fixed to
6dB
21
DBB off (Vol.max.-20dB): 100Hz, -2dB
(r2dB) w.r.t. 1kHz at DBB on
22
Input sens.:Nom. 500 mV 23
for 50mW Limit: 600 mV 24
Line outp.: Nom. mV 25
voltage Limit: mV 26
OUTPUT POWER:
Mains operation: D=10%
2 X 1W 8:
Limit: -1dB 27
28
Music power (MPO) / (PMPO): (acc. to DIN45324) 29
Short term maximum output power: - (acc. to IEC 60268-15) 30
Long term maximum output power: - (acc. to IEC 60268-15) 31
Headphone output voltage/power: n.a. 32
Bandwidth FTC – 1dB at: n.a. (acc. to FTC/16/1/D/432) 33
Bandwidth DIN – 3dB at: - (acc. to IEC 60268-15) 34
Frequency response at Vol. max – 20dB:
typ. 60Hz to 20kHz (r
3dB)
35
LOUDSPEAKER (output):
Low pass crossover frequency: - kHz tolerance: Hz 36
High pass crossover frequency: - kHz tolerance: Hz 37
Short term maximum output power: - W (acc. to IEC 60268-15) 38
Long term maximum output power: - W (acc. to IEC 60268-15) 39
Frequency response at: - Hz kHz 41
REMARKS:
27 : Measured in Tuner mode;
28: CD or Tape mode.
42
