3.5.2
LIST OF ACCESSORIES AND SERVICE
TOOLS
Item Codenumber
Description
1 4822 395 50145
TORX
SCREW
DRIVER SET
2
4822 214 52007
LOW-LEVEL-
TEST
PANEL
ASSY
3
4822
321
61677 CABLE FOR
TEST
PANEL
4 4822 264 50263
PLUG FOR STARTUP
OF
SER-
VICESHELL
ON
PORT 2 (BU 2)
5 4822
397
30096 AUDIO TESTDISC SET
6 4822 397 30155 TESTDISC WITH CONTINOUS
1 KHz SIGNAL 70
MIN.
7
4822 397 30184
AUDIO SIGNALS DISC
8 4822
701
11922
SKEW
DISC 0,6
9
4822
701
11923
EXCENTRICITY DISC
150
I
10
4822
691
30293
ROLLER CONTROLLER
11
4822 691 30298
TRACKER BALL
12 4822
691
30299
JOY STICK
13
4822
691
30297 MOUSE
3.5.2.1 PARTSLIST FOR ROLLERCONTROLLER
Item Codenumber Description
1 4822 321 61841 CABLE ASSY
2 4822
413
90093
BALL
3 4822
276
13359 SWITCH
4 4822
410
62427 KEYTOP-LEFT
4 4822 410 62428 KEYTOP-RIGHT
5 4822
492
42645 SPRING
3.6 THE MONOBOARD CENTRAL REPAIR
PROCEDURE
In case of a defect on the Multi Media Controller (see Block-
diagram) part, the complete panel must be sent
back
to
PCS for repair.
Below a brief description
is
given, a more detailed proce-
dure is available at P.C.S Logistics Management, systems
and Procedure Office.
CODENUMBER Monoboard:
Version
/20
/25
/31
/37
/39
Cod en umber
4822
214
52065
4822
214
52068
4822 214 52069
4822 214 52056
4822
214
52066
•
NSO
or
Customer: send telex
or
on-line MSH system info
to PCS customer relations officer with indicated num-
ber(s) and service 12NC
tor
a repair reference number.
• PCS: send telex
or
MSH info with repair reference num-
ber
and
return invoice price. Also the same number(s)
of
new/repaired items are sent with invoice.
• NSO
or
customer: send defective item(s) to
PCS
at SOM1
by standard address label with repair reference number
and
return invoice to PCS -price center.
• Remark: the difference between the invoice price and
return invoice price gives the 'repair price' for the
NSO
• PCS: send cJefective
item
to
factory and stock.
• Experience has learned that the status
of
the particular
products and packaging needs your local attention.
Prod-
uct~
will be returned in case
of
unacceptable conditions.
REPAIR PROCEDURE CONDITIONS :
* HANDLE WITH
CARE
IN
AN
ESD PROTETECTED
ENVIRONMENT.
* Defective items must be sent back to PHILPS CON-
SUMER SERVICE for repair forwarded by Address
sticker.
•
Put the address sticker properly
on
a free area
of
the
box.
*
Boards must not be reworked
or
damaged.
•
Re-use original package
order
new package in case
of
damages.
•
Remove additional stickers
and
labeling if re-using the
original box. Service codenumber on sticker must be
equal to codenumber
on
repairable item.
I
I!
If the above conditions are not fulfilled, then boards
are
not accepted and the return price will not be credited
!
!l
PCS67 634
