(ONLY FOR /55)
MECHANICAL & ACCESSORIES PARTS LIST - OVERALL VIEW
12 - 7
4 996510020441 MAIN BOARD KB1 996510020508 KEY BOARD MI ASSM
5 996510020532 SERVO BOARD & DVD DRIVE LCD1 996510020530 LCD BOARD
7 (CLR) FRONT PANEL ASS'Y MB1 996510020394 FFC 50P 0.5MM
8 996510020529 RIM MIC1 996510020244 EXTERNAL MICROPHONE 3M
9 (CLR) TFT SCREEN ASS'Y RM0 996510020533 REMOTE CONTROL
21 (CLR) SLIDE BRACKET ASS'Y SD1 996510020498 USB/SD/AUX BOARD
24 996510020435 AUDIO WIRE 19P TFT0 996510020514 TFT DRIVE BOARD
FFC1 996510020395 FFC 8P 1.0mm
FFC2 996510020396 FFC 24P 0.5mm
FFC3 996510020434 FFC 14P REMARK: CLR=COMPONENTS LEVEL REPAIR
MECHANICAL PARTS LIST - FRONT PANEL ASS'Y
PAL2 996510020430 BT BUTTON 2 PAL19 996510020425 EJECT BUTTON BKT
PAL3 996510020429 BT BUTTON 1 PAL20 996510020423 USB BKT
PAL5 996510020427 DECO BRZ+TI PAL21 996510020426 REMOTE LENS
PAL6 996510020428 DECO-PLT+TI PAL23 996510020433 GUIDE BKT
PAL7
996510020418
FRONT PANEL
PAL24
996510020420
5D BUTTON
PAL7
996510020418
FRONT
PANEL
PAL24
996510020420
5D
BUTTON
PAL8 996510020432 BT BUT BKT PAL25 996510020424 EJECT BUTTON
PAL9 996510020421 VOL LI-GUIDE PAL44 996510020422 DIR LI-GUIDE
PAL10 996510020419 VOL KNOB
PAL15 996510020431 REM BKT
PAL17 996510020417 SRC BUTTON
MECHANICAL PARTS LIST - SLIDE BRACKET ASS'
Y
SLI20 996510020391 VM-700 GEAR 6
SLI21 996510020387
VM-700 GEAR 2
SLI22 996510020383 VM-700 GEAR 3
SLI23 996510020369 VM-700 GEAR 1
SLI24 996510020386 VM-700 GEAR 4 PA
SLI25 996510020390 VM-700 GEAR 5 PA
SLI26 996510020385 VM-700 BEVEL WHEEL-A PA
SLI28 996510020372 VM-700 GEAR 7
SLI33
996510020384
VM 700 BEVEL WHEEL B PA
SLI33 996510020384 VM-700 BEVEL WHEEL-B P
A
MECHANICAL PARTS LIST - MAIN BOARD ASS'
Y
8
996510020443
FAN
8
996510020443
FAN
