Philips CED750/55 - Page 47

ELECTRICAL PARTS LIST - MAIN BOARD ELECTRICAL PARTS LIST - MAIN BOARD
12 - 10
Q120 996510020493 TR KN12907A(PNP) SOT-23 U45 996510020472 IC 74HCT4052DB SSOP16
Q121 996510020493 TR KN12907A(PNP) SOT-23 U48 996510020473 IC 74HC00 SOP14
Q122 996510019571 TRANSISTOR 2N3904(NPN) U50 996510019713 IC UTC4558 SOP-8
Q123 996510020461 TR KRA304 USM U61 996510020479 IC BA7071 SOP8 ROHM
Q124 996510020463 TR KTD1304 SOT-23 KEC U8 996510019659 IC FMS6502 TSSOP24
Q127 996510020463 TR KTD1304 SOT-23 KEC U902 996510031373 MODULE BLUETOOTH/CED750
Q13 996510019571 TRANSISTOR 2N3904(NPN) WIR4 996510020442 WIRE HARNES 2P
Q137 996510019571 TRANSISTOR 2N3904(NPN) X3 996510020470 TCXO 8.00M
Q138 996510019571 TRANSISTOR 2N3904(NPN) ZD1 996510020454 ZENER DIODE 5.6V
Q139 996510019571 TRANSISTOR 2N3904(NPN) ZD105 996510020453 ZENER DIODE 18V
Q141 996510019570 TRANSISTOR MMBT3906LT1(PNP) ZD107 996510020453 ZENER DIODE 18V
Q18 996510020461 TR KRA304 USM ZD16 996510020455 ZENER DIODE 3.3V
Q2
996510019571
TRANSISTOR 2N3904(NPN)
ZD17
996510020471
ZENER DIODE
Q2 996510019571 TRANSISTOR 2N3904(NPN) ZD17 996510020471 ZENER DIODE
Q24 996510020461 TR KRA304 USM ZD18 996510019580 ESD DIODE PG05GBUSV 200W
Q3 996510019571 TRANSISTOR 2N3904(NPN) ZD2 996510019580 ESD DIODE PG05GBUSV 200W
Q31 996510020462 TR KRC402 USM ZD3 996510020455 ZENER DIODE 3.3V
Q34 996510019571 TRANSISTOR 2N3904(NPN) ZD35 996510019580 ESD DIODE PG05GBUSV 200W
Q36 996510020462 TR KRC402 USM
Q5
996510020463
TR KTD1304 SOT
-
23 KEC
Q5
996510020463
TR
KTD1304
SOT
-
23
KEC
Q6 996510020462 TR KRC402 USM
Q7 996510019571 TRANSISTOR 2N3904(NPN)
ELECTRICAL PARTS LIST - USB/SD/AU
X
Q8 996510020463 TR KTD1304 SOT-23 KEC BOARD
Q9 996510020462 TR KRC402 USM
RN128 996510020481 V-RES AVX CON1 996510020499 SOCKET 4P 2.0mm USB2.0
RN7 996510020481 V-RES AVX CON3 996510020502 FFC SOCKET 24P
CON4 996510019625 12P 2.5MM SD/MMC SOCKET
SD5 996510019698 SCHTTKY DIODE RB551 0.5A 20V U1 996510020500 SOCKET EARPHONE
SD6 996510019698 SCHTTKY DIODE RB551 0.5A 20V
TC102 996510020497 TAN.CAP 47uF
TC106 996510020496 TAN.CAP 220uF
U1 996510019656 IC TDA7419TR SO28 ST
ELECTRICAL PARTS LIST - MOTO
R
U100
996510019650
IC E TDA7386 FLEXIWATT25 ST
BOARD
U100 996510019650 IC E-TDA7386 FLEXIWATT25 ST
BOARD
U101 996510019672 IC KIA78M08 DPAK KEC
U105 996510020490 IC TL1451ACD SOIC16 CN4001 996510020506 FFC SOCKET 12P
U11 996510020475 IC 78L05L SOT-89 UTC D4000 996510020503 SW DIODE
U119 996510019672 IC KIA78M08 DPAK KEC D4001 996510020503 SW DIODE
D4002 996510020503 SW DIODE
U13 996510020469 IC XC6202P332PR L4001 996510019653 INDUCTOR 10uH 0805
U134
996510020467
IC LD1117A 1 8V
U134
996510020467
IC
LD1117A
-
1
.
8V
U15 996510020468 IC RT9161A-50X U4000 996510020507 IC L7809CV TO-220 ST
U16 996510020468 IC RT9161A-50X U4001 996510020505 OPTICAL ELECTRONIC
U2 996510020476 IC 78L09 SOT-89 KEC U4003 996510020475 IC 78L05L SOT-89 UTC
U4004 996510020504 IC BA6951FS
U20 996510019713 IC UTC4558 SOP-8
U21 996510020474 IC 74HC4053PW TSSOP-1
U23 996510020477 IC 79L05 SOT-89 UTC
U23
996510020477
IC
79L05
SOT 89
UTC
U3 996510020480 IC BA6287F SOP-8 ROMH
U44 996510031158 IC ATMEGA1280-16AU/CED750
