Philips DVD707 - Page 27

Spare parts list DVD707/782
27
MPEG Board 3141 018 02480
MISCELLANEOUS
1304 4822 267 40624 5-FOLD X
1307 2422 025 09904 CON BM V 4P M 2.50 XH B
1311 3141 010 30340 CON BM V 40P M 2.54 103308B
1312 2422 025 09074 CONNECTOR 8P TOP
1313 3141 010 30070 MICRO-SHUNT V 2P M 2.54
1320 3141 010 30300 CON BM CINCH V 3P F GNBURD
1321 3141 010 30320 CON BM CINCH V 6P F B
1322 3141 010 30250 CON S-VEDIO AND CVBS
1323 3141 010 30310 CON BM CINCH V 3P F WHRDBK B
1325 3141 018 40180 SWI TACT 2P 20MA 15V EVQ21 A
CAPACITORS
2301 5322 122 32531 100PF 5%NP0 50V
2302 5322 122 32531 100PF 5%NP0 50V
2303 4822 126 14585 100NF 10% X7R 0805 50V
2304 5322 122 32531 100PF 5%NP0 50V
2305 5322 122 32531 100PF 5%NP0 50V
2306 5322 122 32531 100PF 5%NP0 50V
2307 5322 122 32531 100PF 5%NP0 50V
2308 5322 122 32531 100PF 5%NP0 50V
2309 5322 122 32531 100PF 5%NP0 50V
2310 5322 122 32531 100PF 5%NP0 50V
2311 4822 126 14585 100NF 10% X7R 0805 50V
2313 2020 012 93504 ELCAP KA 16V S 100U PM20 A
2314 4822 126 14585 100NF 10% X7R 0805 50V
2315 4822 126 14585 100NF 10% X7R 0805 50V
2316 4822 124 23624 47UF20% 16V
2317 4822 126 14585 100NF 10% X7R 0805 50V
2318 4822 124 23624 47UF20% 16V
2319 4822 126 14585 100NF 10% X7R 0805 50V
2320 4822 126 14585 100NF 10% X7R 0805 50V
2322 4822 126 14585 100NF 10% X7R 0805 50V
2324 4822 126 14585 100NF 10% X7R 0805 50V
2325 4822 126 14585 100NF 10% X7R 0805 50V
2326 4822 124 23624 47UF20% 16V
2327 4822 126 14585 100NF 10% X7R 0805 50V
2328 4822 124 23624 47UF20% 16V
2331 4822 126 14585 100NF 10% X7R 0805 50V
2333 4822 126 14585 100NF 10% X7R 0805 50V
2336 4822 126 14585 100NF 10% X7R 0805 50V
2337 4822 124 40207 100UF20% 25V
2338 4822 126 14585 100NF 10% X7R 0805 50V
2339 5322 122 32531 100PF 5%NP0 50V
2340 5322 122 32531 100PF 5%NP0 50V
2341 5322 122 32531 100PF 5%NP0 50V
2342 5322 122 32531 100PF 5%NP0 50V
2343 5322 122 32531 100PF 5%NP0 50V
2344 5322 122 32531 100PF 5%NP0 50V
2345 5322 122 32531 100PF 5%NP0 50V
2346 5322 122 32531 100PF 5%NP0 50V
2347 4822 126 14585 100NF 10% X7R 0805 50V
2348 4822 124 40207 100UF20% 25V
2349 4822 126 14585 100NF 10% X7R 0805 50V
2350 4822 126 13486 15PF 2% NP0 63V
2351 4822 126 14585 100NF 10% X7R 0805 50V
2355 4822 126 14585 100NF 10% X7R 0805 50V
2356 4822 126 14585 100NF 10% X7R 0805 50V
2357 4822 126 14585 100NF 10% X7R 0805 50V
2358 5322 122 32658 22PF 5% 50V
2359 5322 122 32658 22PF 5% 50V
2361 2020 012 93504 ELCAP KA 16V S 100U PM20 A
2362 4822 124 23624 47UF20% 16V
2363 2020 012 93505 ELCAP KA 25V S 10U PM20 A
2364 4822 126 13473 220NF80-20% 50V
2365 5322 122 32658 22PF 5% 50V
2366 4822 126 14585 100NF 10% X7R 0805 50V
2367 5322 122 32659 33PF 5% 50V
2368 4822 126 14585 100NF 10% X7R 0805 50V
2369 4822 124 40207 100UF20% 25V
2370 2222 580 19809 CER2 0805 Y5V 50V 47N COL R
2371 4822 126 14585 100NF 10% X7R 0805 50V
2373 4822 126 14585 100NF 10% X7R 0805 50V
2375 4822 124 23624 47UF20% 16V
2376 4822 124 23624 47UF20% 16V
2378 4822 126 14585 100NF 10% X7R 0805 50V
2379 4822 126 14585 100NF 10% X7R 0805 50V
2380 4822 126 14585 100NF 10% X7R 0805 50V
2381 4822 126 14585 100NF 10% X7R 0805 50V
2382 4822 126 14585 100NF 10% X7R 0805 50V
2385 4822 126 14585 100NF 10% X7R 0805 50V
2386 4822 126 14585 100NF 10% X7R 0805 50V
2391 4822 124 40433 47UF20% 25V
2392 4822 124 40433 47UF20% 25V
2393 4822 126 14585 100NF 10% X7R 0805 50V
2394 4822 126 14585 100NF 10% X7R 0805 50V
2398 4822 124 81108 0,47UF20% 50V
2401 4822 126 14585 100NF 10% X7R 0805 50V
2403 4822 124 23624 47UF20% 16V
2404 4822 126 14585 100NF 10% X7R 0805 50V
2406 4822 124 81108 0,47UF20% 50V
2411 4822 126 14585 100NF 10% X7R 0805 50V
2412 5322 122 32658 22PF 5% 50V
2413 4822 124 40196 220UF20% 16V
2414 4822 126 14585 100NF 10% X7R 0805 50V
2415 4822 126 14585 100NF 10% X7R 0805 50V
2416 4822 126 14585 100NF 10% X7R 0805 50V
2420 4822 126 14585 100NF 10% X7R 0805 50V
2421 5322 122 32658 22PF 5% 50V
2422 4822 124 40196 220UF20% 16V
2423 4822 124 23624 47UF20% 16V
2426 5322 122 32658 22PF 5% 50V
2427 4822 124 40196 220UF20% 16V
2428 4822 126 14585 100NF 10% X7R 0805 50V
2429 4822 126 14585 100NF 10% X7R 0805 50V
2433 4822 126 14585 100NF 10% X7R 0805 50V
2434 2020 012 93504 ELCAP KA 16V S 100U PM20 A
2435 5322 122 33861 120PF10% 50V
2436 2020 012 93505 ELCAP KA 25V S 10U PM20 A
2437 2020 012 93505 ELCAP KA 25V S 10U PM20 A
2438 4822 126 13344 1,5NF 5% 63V
2440 2020 012 93505 ELCAP KA 25V S 10U PM20 A
2441 5322 122 33861 120PF10% 50V
2442 2020 012 93505 ELCAP KA 25V S 10U PM20 A
2443 4822 126 13344 1,5NF 5% 63V
2444 4822 126 14585 100NF 10% X7R 0805 50V
2445 4822 126 14585 100NF 10% X7R 0805 50V
2446 5322 122 33861 120PF10% 50V
2447 2020 012 93505 ELCAP KA 25V S 10U PM20 A
2448 2020 012 93505 ELCAP KA 25V S 10U PM20 A
2449 4822 126 13344 1,5NF 5% 63V
2450 2020 012 93505 ELCAP KA 25V S 10U PM20 A
2451 5322 122 33861 120PF10% 50V
2452 2020 012 93505 ELCAP KA 25V S 10U PM20 A
2453 4822 126 13344 1,5NF 5% 63V
2454 4822 126 14585 100NF 10% X7R 0805 50V
2455 4822 126 14585 100NF 10% X7R 0805 50V
2456 5322 122 33861 120PF10% 50V
2457 2020 012 93505 ELCAP KA 25V S 10U PM20 A
2458 2020 012 93505 ELCAP KA 25V S 10U PM20 A
2459 4822 126 13344 1,5NF 5% 63V
2460 2020 012 93505 ELCAP KA 25V S 10U PM20 A
2461 5322 122 33861 120PF10% 50V
2462 2020 012 93505 ELCAP KA 25V S 10U PM20 A
2463 4822 126 13344 1,5NF 5% 63V
2464 4822 126 14585 100NF 10% X7R 0805 50V
2465 5322 122 32531 100PF 5%NP0 50V
2466 5322 122 32531 100PF 5%NP0 50V
2467 5322 122 32658 22PF 5% 50V
RESISTORS
3305 4822 051 20339 33R00 5% 0,1W
3309 4822 051 20008 0R00 JUMP. (0805)
3311 4822 051 20474 470K00 5% 0,1W
3312 4822 117 10833 10K 1% 0,1W
3313 4822 117 10833 10K 1% 0,1W
3314 4822 051 20102 1K00 5% 0,1W
3315 4822 117 13577 330R 1% RC12H 0805 1,25W
3316 4822 051 20919 91R00 5% 0,1W
3318 4822 051 20102 1K00 5% 0,1W
3319 2120 108 94042 RST NETW SM RAC16 4X22R PM5 R
3320 2120 108 94042 RST NETW SM RAC16 4X22R PM5 R
3324 4822 117 10837 100K 1% 0.1W
3325 4822 117 10837 100K 1% 0.1W
3326 4822 051 20478 4R70 5% 0,1W
3327 4822 117 10837 100K 1% 0.1W
3328 4822 117 10837 100K 1% 0.1W
3329 4822 117 10837 100K 1% 0.1W
3330 4822 117 10837 100K 1% 0.1W
