Technical specifications
Playback system
• SACD multi-channel
• SACD Stereo
• DVD-Video
• Video CD (VCD)
• S-Video CD (SVCD)
• MP3-CD
• CD (CD-R and CD-RW)
1
• DVD+RW
Optical read-out system
• Laser type: Semiconductor AlGaAs
• Numerical Aperture:
0.60 (DVD), 0.45 (VCD/SVCD/CD)
• Wavelength:
650 nm (DVD), 780 nm (VCD/SVCD/CD)
DVD disc format
• Medium: Optical disc
• Diameter: 12cm (8cm)
• Playing time: (12cm)
One layer: 2.15 h
2,
Dual layer: 4 h
2
Two side, single layer: 4.30 h
2
Two side, dual layer: 8 h
2
TV standard
• PAL: 50Hz, 625 lines, Multi-standard Playback
• NTSC: 60Hz, 525 lines, Multi-standard Playback
Audio format
• Digital
DSD: Uncompressed digital
MPEG/Dolby: Compressed digital,
Digital/DTS/PCM: 16, 20, 24 bits, fs 44.1, 48, 96kHz
MP3 (ISO 9660: 96, 112, 128, 256kbps and
variable bit rate, fs 32,44.1, 48kHz
• Full decoding of Dolby Digital and DTS
multi-channel sound
• Analog Sound Stereo
• Dolby surround compatible downmix from
Dolby Digital multi-channel sound
• 3D Sound for virtual 5.1 channel sound
on 2 speakers
Video format
• Digital compression: MPEG 2 for DVD and SVCD,
MPEG 1 for VCD
DVD 50Hz 60Hz
Horiz. resolution 720 pixels 720 pixels
Vertical resolution 576 lines 480 lines
VCD 50Hz 60Hz
Horiz. resolution 352 pixels 352 pixels
Vertical resolution 288 lines 240 lines
SACD audio performance
D/A converter: DSD
SACD: fs 2.8224Mhz, DC-100kHz
Max. output: 2V rms
voltage (OdB)
Channel unbalance: <0.5dB
Cut-off frequency: 40kHz
• Signal-Noise (1kHz): 115dB
• Dynamic Range (1kHz): 108dB
• Crosstalk (1kHz): 110dB
• Total harmonic distortion (1kHz): 100dB
Audio performance (no upsampling)
• D/A converter
DVD: (24 bits)Fs 96kHz, 4Hz-44kHz
(24 bits)Fs 48kHz, 4Hz-22kHz
CD/Video CD: (24 bits)Fs 44.1kHz, 4Hz-20kHz
S-Video CD: (24 bits)Fs 48 kHz, 4 Hz-22 kHz
(24 bits)Fs 44.1kHz, 4Hz-20kHz
• Signal-Noise (1kHz): 105dB
• Dynamic Range (1kHz): 105dB
• Crosstalk (1kHz): 105dB
• Total harmonic distortion (1kHz): 100dB
Video performance
• YUV output
Y: 1 Vpp into 75ohm, CrCb: 0.7 Vpp into 75ohm
• S-Video Output
Y: 1 Vpp into 75ohm, C: 0.3 Vpp into 75ohm
• Video output: 1 Vpp into 75ohm
• Black Level Shift: On/off
• Video Shift: Left/right
Connections
• Y, Cb, Cr output(480i/p): Cinch 3x (green, blue,red)
• S-Video output: Mini DIN, 4 pins
• Video Output: Cinch (yellow) 2x
• Audio L+R output: Cinch (white/red)
• Digital Output: 1 coaxial, 1 optical, IEC958
for CDDA/LPCM, IEC1937 for MPEG1/2,
Dolby Digital, DTS
6 Channel analog output
• Audio Front L/R: Cinch (white/red)
• Audio Surround L/R: Cinch (white/red)
• Audio Centre: Cinch (blue)
• Audio Subwoofer: Cinch (black)
Power supply
• Power inlet: 110V, 60Hz
• Power usage: Approx. 20 watt
• Power usage standby: Less than 4 watt
Product
• Dimension 17 x 3.9 x 12.4 inches (w x h x d)
• Weight Approx. 9.5 lbs
Carton
• Dimension 20.6 x 8 x 15.7 inches (w x h x d)
Package contents
• DVD-video player
• Remote control with batteries
• User manual
• Video cable/Audio cable
• AC power cord
General functionality
• Stop/play/pause
• Fast forward/backward
• Step forward/backward
• Slow motion
• Title/chapter/track select
• Skip next/skip previous
• Repeat (Chapter/title/all) or (Track/all)
• A-B repeat, Shuffle & Scan
• Zoom (x1.33, x2, x4) with picture enhancement
• 3D sound
• 5.1 Channels user defined speaker settings
• Virtual Jog Shuttle
• Enhanced smart picture with Monitor type selector
• SACD/CD Text
• Resume (5 disc) after stop/standby
3
• Parental Control and Disc lock (120 disc)
• NTSC/PAL conversion
• Smart power off for better energy saving
• Advanced SACD bass management
• Audio Upsampling
• Audio Direct Mode
• Crystal Clear Pro
DVD functionality
• Multi-angle selection
• Audio selection (1 out of max. 8 languages)
• Subtitles selection (1 out of max. 32 languages)
• Aspect ratio conversion (16:9, 4:3 letterbox,4:3 Pan Scan)
• Disc Menu support (title menu and root menu)
Video CD, SVCD functionality
• Playback control for VCD 2.0 discs and SVCD
• Audio Selection (1 out of max. 4 languages) for SVCD
MP3 functionality
• Time display (Track)
• Album and track selection
• Repeat (disc/album/track)
• Nested directory levels supported to 8 levels
• Max. albums possible is 32
• Max. number of tracks is 999
1 Applicable for finalized mult-session discs also.
2 Typical playing time for movie with 2 spoken
languages and 3 subtitle languages.
3 Applicable only for DVD,VCD, SVCD discs
UPC Code: 0 3784 992792 2
Printed in USA ©2002 Philips Consumer Electronics A Division of
Philips Electronics North America Corp. Specifications subject to
change without notice.The products and services described here
will not necessarily become available in the market.This document
contains preliminary information.All rights reserved. DVD963SA-USA
Dolby and the double-D symbol are trademarks of Dolby Laboratories
Licensing Corporation. DTS is a registered trademark of Digital
Theater Systems, Inc.
www.philips.com or AOL keyword: Philips
DVD-Video/SACD Player
DVD963
SA
DVD
963
SA
