7-3
DVP3126K/XX,DVP3146K/XX,DVP3148K/XX Mechanical Exploded View
Remark: It's a general Mechanical Exploded View for DVP3126K/XX,DVP3146K/XX,DVP3148K/XX
Detailed information please refer to Model set.
Ass'y1 is the assembled component for location 1,3,4,5,27
