7-3
DVP3142(K/KM)/XX, DVP3144K/55 Mechanical Exploded View
Remark: It's a general Mechanical Exploded View for DVP3142(K/KM)/XX, DVP3144K/55,
Detailed information please refer to Model set.
Ass'y1 is the assembled component for location1,3,4,5,27
