Mechanical and Dismantling Instructions
Dismantling Instruction
Step5: Dismantling Front Panel, disconnect the 3 connector, then release the snaps on the both sides of Front Panel and bottom
cabinet , then gently pull the Panel out from the set. (Figure 5 & 6 & 7)
Snap 1
Figure 6
Snap 2
Figure 7
Figure 5
CON 4
CON 6
CON 5
2-3
