Philips GC4430 Service Manual

GC4430
BACKPLATE 7
BALL SWIVEL 8
Remove Screw A
Remove BACKPLATE 7
B2B1
FILLING DOOR ASSY 10
INLAY ASSY 11
SOS KNOB 24
SPRAY KNOB 25
ASO ASSY 27
IONIC ON/OFF BUTTON 33
LIGHT RING 34
Remove Screws B1, B2
Remove Cord Clamp
Release 2x rear catches of
INLAY ASSY 11
Remove INLAY ASSY 11
DISASSEMBLY ADVICE
TANK SEAL 21
HOUSING ASSY 22
THERMOSTAT BUSH 28
THERMOSTAT PLATE
PRINTED 29
THERMOSTAT RING 30
AESTHETIC RING 31
SOFT TOUCH SNAP-ON 35
LINNE
B.WOLLE
W
OLLE
NYLON
NYLON
YLLE
SEIDE
SILKE
BOMULE
LEINEN
Remove Thermostat dial
Remove Screws C1, C2
Remove Screws D1, D2
Remove HOUSING 22
WATER TANK ASSY 14
PUMP ASSY 16
SPRAY NOZZLE ASSY 17
STEAM SHAFT ASSY 18
DOSING CAM 19
CLAMP BRACKET 20
Remove Screws E1, E2
Remove Screw F
Remove WATER TANK ASSY 14
Remove Screws G1, G2
Remove CLAMP BRACKET 20
COVER SPRAYED 1
SOLEPLATE MOUNTED
ASSY 2
SOS SEAL 3
DOISNG SEAL 5
HEAT SHIELD 6
IONISER ASSY 36
Remove Screw H1
Remove HEAT SHIELD 6
Remove IONISER ASSY 36
Remove Screws H2, H3
Remove COVER SPRAYED 1
2-5

Philips GC4430 Specifications

Power

power	2400 W
voltage	220-240 V
frequency	50-60 Hz

Steam Performance

steam boost	100 g/min
continuous steam	40 g/min
watertank capacity	335 ml

Weight and Dimensions

product dimensions	303 x 120 x 152 cm
product weight	1.55 kg
