PCS 101 496
DISASSEMBLY / ASSEMBLY ADVICE
TO OPEN THE PRODUCT
Remove STYLING COMB ( 1, 2 )
Remove CUTTER ( 3 )
Remove TRIMMER CLAMP ( 4 )
Remove CAP ( 5 )
Remove ZOOM RING ( 6 ) +
COMBHOLDER ( 7 )
N.B. falls down
Open HOUSING ( 14 )
1
ASSEMBLY ADVICE
Take care, that the nocks of the
comb holder ( 7 ), fi t perfectly into
the grooves of the zoom ring ( 6 )
