Philips HTB3570/12 Service Manual

Pin Symbol Type Description
Audio PWM DAC interface
D12 AVDD33_DAC
Power 3.3V Analog Power
E11 AVSS33_DAC
Ground Analog Ground
A10 AL0 I/O
Multiple function:
(1) Audio output bit clock
(2) Audio PWM output
(3) GPIO
B10 AR0 I/O
Multiple function:
(1) Audio output master clock
(2) Audio PWM output
(3) GPIO
Audio interface
U5 AMUTE I/O
Multiple function:
(1) 1st Audio DAC mute
(2) GPIO
C10 AOLRCK I/O
Multiple function:
(1) Audio output left-right clock
(2) 2nd Audio DAC mute
(3) Video out DE signal
(4) 2nd RS232 TX
(5) External Interrupt 4
(6) Slave I2C clock
(7) PWM control signal output
(8) Ethernet Activity LED
(9) GPIO
D10 AOSDATA0 I/O
Multiple function:
(1) Audio output serial data 0
(2) 2nd Audio DAC mute
(3) Video out DE signal
(4) 2nd RS232 RX
(5) External Interrupt 2
(6) Slave I2C data
(7) PWM control signal output
(8) Ethernet Duplex LED
(9) GPIO
9-6

Philips HTB3570/12 Specifications

General

Brand	Philips
Model	HTB3570/12
Category	Home Theater System
Language	English
