Philips HTB3570/12 Service Manual

Pin Symbol Type Description
G25 VOUTD0
I/O
Multiple function:
(1) Video out 16-bit 422 mode: C0
(2) External Interrupt 4
(3) 3th RS232 RX
(4) Ethernet Link LED
(5) NAND Flash Data input/output bit 4
(6) Secure Disk interface data bit 1
(7) GPIO
G24 VOUTD1
I/O
Multiple function:
(1) Video out 16-bit 422 mode: C1
(2) Slave I2C clock
(3) NAND Flash Data input/output bit 3
(4) Secure Disk interface data bit 2
(5) GPIO
F25 VOUTD2
I/O
Multiple function:
(1) Video out 16-bit 422 mode: C2
(2) Slave I2C data
(3) NAND Flash Data input/output bit 2
(4) Secure Disk interface data bit 3
(5) GPIO
G23 VOUTD3
I/O
Multiple function:
(1) Video out 16-bit 422 mode: C3
(2) JTAG ICE data out
(3) GPIO
E25 VOUTD4
I/O
Multiple function:
(1) Video out 16-bit 422 mode: C4
(2) JTAG ICE clock
(3) GPIO
F24 VOUTD5
I/O
Multiple function:
(1) Video out 16-bit 422 mode: C5
(2) JTAG ICE mode select
(3) GPIO
D25 VOUTD6
I/O
Multiple function:
(1) Video out 16-bit 422 mode: C6
(2) JTAG ICE data in
(3) GPIO
E24 VOUTD7
I/O
Multiple function:
(1) Video out 16-bit 422 mode: C7
(2) Audio line input data
(3) GPIO
9-9
