Philips HTB3570/12 Service Manual

Pin Symbol Type Description
B24 VOUTD13
I/O, 5V
Multiple function:
(1) Video out 16-bit 422 mode: Y5
(2) SPDIF input bit clock
(3) 2nd RS232 RX
(4) Slave I2C data
(5) External Interrupt 1
(6) Ethernet Duplex LED
(7) NAND Flash command latch enable
(8) GPIO
A24 VOUTD14
I/O, 5V
Multiple function:
(1) Video out 16-bit 422 mode: Y6
(2) SPDIF input left-right clock
(3) 3th RS232 TX
(4) Slave I2C clock
(5) External Interrupt 2
(6) Ethernet Speed LED
(7) NAND Flash address latch enable
(8) GPIO
E23 VOUTD15
I/O
Multiple function:
(1) Video out 16-bit 422 mode: Y7
(2) SPDIF input data
(3) 3th RS232 RX
(4) Slave I2C data
(5) External Interrupt 4
(6) Ethernet Link LED
(7) NAND Flash write enable
(8) GPIO
HDMI TX
C16
AVDD12_HDMI
_C
Power 1.2V Analog Power
C15
AVDD12_HDMI
_D
Power 1.2V Analog Power
D14 AVDD33_HDMI
Power 3.3V Analog Power
E14 AVSS33_HDMI
Ground Analog Ground
A15 CH0_M
Analog HDMI TX data 0 differential pair (M)
B15 CH0_P
Analog HDMI TX data 0 differential pair (P)
A14 CH1_M
Analog HDMI TX data 1 differential pair (M)
B14 CH1_P
Analog HDMI TX data 1 differential pair (P)
A13 CH2_M
Analog HDMI TX data 2 differential pair (M)
B13 CH2_P
Analog HDMI TX data 2 differential pair (P)
A16 CLK_M
Analog HDMI TX clock differential pair (M)
9-11
