Pin Symbol Type Description

AE13

RDQ3_B

I/O

Memory data bit 3

AD21

RDQ4_B

I/O

Memory data bit 4

AC21

RDQ5_B

I/O

Memory data bit 5

AD20

RDQ6_B

I/O

Memory data bit 6

AC20

RDQ7_B

I/O

Memory data bit 7

AC15

RDQ8_B

I/O

Memory data bit 8

AC16

RDQ9_B

I/O

Memory data bit 9

AB15

RDQ10_B

I/O

Memory data bit 10

AB14

RDQ11_B

I/O

Memory data bit 11

AC19

RDQ12_B

I/O

Memory data bit 12

AE18

RDQ13_B

I/O

Memory data bit 13

AE19

RDQ14_B

I/O

Memory data bit 14

AD18

RDQ15_B

I/O

Memory data bit 15

AB16

RDQM0_B

Memory data mask bit 0

AA15

RDQM1_B

Memory data mask bit 1

AD16

RDQS0_B

I/O

Memory positive data strobe bit 0

AE16

RDQS0__B

I/O

Memory negative data strobe bit 0

AD17

RDQS1_B

I/O

Memory positive data strobe bit 1

AC17

RDQS1__B

I/O

Memory negative data strobe bit 1

AD10

RODT_B

Memory on die termination enable

AE11

RRAS__B

Memory row address strobe

Y18

RVREF0_B

Memory VREF

AA12

RWE__B

Memory write enable

AE7

RRESET_B

Memory reset

MISC

A19

CEC

I/O, 5V

Multiple function

(1) HDMI CEC

(2) GPIO

(3) JTAG ICE data in

9-16
