Philips HX6511 - Page 3

HX6511, HX6530(handle),
HX6581 & HX6582
4235-057-56461 _ 13-08-02
(YY_MM_DD)
3-4
PARTS LIST AND EXPLODED VIEW
SERVICE MANUAL - PIXIE / EASY CLEAN
EasyClean (HX6511)
Pos Service Code Description Comments
1
4235 010 18931 TRAVEL CHARGER - US, CANADA
4235 010 18941 TRAVEL CHARGER - EURO, UAE, SOUTH AFRICA
4235 010 18951 TRAVEL CHARGER – UK
4235 090 02571
TRAVEL CHARGER – HONG KONG, UK, SINGAPORE,
PHILIPPINES, MALAYSIA
4235 090 02541 TRAVEL CHARGER - JAPAN KOIZUMI
4235 090 02591 TRAVEL CHARGER - JAPAN YOSHIDA
4235 090 02551 TRAVEL CHARGER - KOREA
4235 090 02561 TRAVEL CHARGER - TAIWAN
4235 090 02531 TRAVEL CHARGER - CHINA
4235 090 02581 TRAVEL CHARGER - AUSTRALIA
4235 090 00971 TRAVEL CHARGER - RUSSIA
2
8816 011 60540 PRO RESULTS BRUSH HEAD, REMINDER BRISTLES - US
8816 011 21522 PRO RESULTS BRUSH HEAD, REMINDER BRISTLES - CANADA
8816 011 05031
PRO RESULTS BRUSH HEAD, REMINDER BRISTLES - EURO,
SOUTH AFRICA, UK, RUSSIA
8816 011 05551
PRO RESULTS BRUSH HEAD, REMINDER BRISTLES - HONG
KONG, SINGAPORE, PHILIPPINES, MALAYSIA
8816 012 05461 PRO RESULTS BRUSH HEAD, REMINDER BRISTLES - KOIZUMI
8816 012 05461
PRO RESULTS BRUSH HEAD, REMINDER BRISTLES -
YOSHIDA
8816 011 05571 PRO RESULTS BRUSH HEAD, REMINDER BRISTLES - KOREA
8817 001 05861 PRO RESULTS BRUSH HEAD, REMINDER BRISTLES - TAIWAN
8817 01 05811 PRO RESULTS BRUSH HEAD, REMINDER BRISTLES - CHINA
8816 013 05341
PRO RESULTS BRUSH HEAD, REMINDER BRISTLES -
AUSTRALIA
3 4235 090 01951 HANDLE ONLY - US, CANADA
4235 090 02901 HANDLE ONLY - EURO, UK, UAE, SOUTH AFRICA, RUSSIA
4235 090 02171 HANDLE ONLY - CHINA
4235 090 02181 HANDLE ONLY - REST OF ASIA
Not available as a Service
Part. Only available as
warranty. Hanlde warranty
claims must be routed to
Call Centers for
replacement.
Available as a Service part.
Warranty claims should be
routed to Call Centers.
Available as a Service part.
Warranty claims should be
routed to Call Centers.
