3 - 2
Preparations
B
Antennas Connection
Connect the supplied AM loop antenna and FM
antenna to the respective terminals. Adjust the
position of the antenna for optimal reception.
AM Antenna
Position the antenna as far as possible from a TV,
VCR or other radiation source.
Rear connections
The type plate is located at the rear of the
system.
For users in the U.K.: please follow the
instructions on page 2.
A
Power
Before connecting the AC power cord to the
wall outlet, ensure that all other connections
have been made.
WARNING!
– For optimal performance, use only the
original power cable.
– Never make or change any connections
with the power switched on.
To avoid overheating of the system, a safety
circuit has been built in. Therefore, your
system may switch to Standby mode
automatically under extreme conditions. If
this happens, let the system cool down
before reusing it (not available for all versions).
Preparations
FM Antenna
Extend coil antenna at the back of the unit fully
for optimum reception.
C
Speakers Connection
Front Speakers
Connect the speaker wires to the SPEAKERS
terminals, right speaker to "RIGHT" and left
speaker to "LEFT", coloured (marked) wire to
"+ " and black (unmarked) wire to "- ".
Fully insert the stripped portion of the speaker
wire into the terminal as shown.
Notes:
– For optimal sound performance, use the
supplied speakers.
– Do not connect more than one speaker to any
one pair of
+
/
-
speaker terminals.
– Do not connect speakers with an impedance
lower than the speakers supplied. Please refer to
the SPECIFICATIONS section of this manual.
Before using the remote control
1
Pull out the plastic protective sheet.
2
Select the source you wish to control by
pressing one of the source select keys on the
remote control (for example CD, TUNER).
3
Then select the desired function (for example
2 ,
¡ ,
™ ).
A
B
REPEAT
SHUFFLE
SLEEP
VOL
Replacing battery (lithium
CR2025) into the remote control
1
Pull out the knob
A
slightly to the right.
2
Pull out the battery compartment
B
.
3
Replace a new battery and fully insert the
battery compartment back to the original
position.
CAUTION!
Batteries contain chemical substances, so
they should be disposed off properly.
PUSH
PULL
CONTROLS AND CONTROLS
