DISASSEMBLY INSTRUCTION
1. Remove Left & Right Cabinet
-
remove screws M3x10 - 4 pcs
2. Remove Top Cabinet
a. remove screws M3x8 - 2 pcs & 2 pcs
b. lift the Top Cabinet
3. Separate Front and Back Cabinet.
a. remove screws T3x8 - 2 pcs.
D
B
E
b. remove screws T3x6 - 2 pcs.
- Pull the left or right cabinet and then lift it.
C
C
C
E
E
c. release the catches.
F
5. Remove Amplifier board
a. remove screws T3x4 - 1 pcs
J
4. Separate rar and bottom Cabinet.
a. remove screws T3x6 - 6 pcs.
G
H
b. remove screws T3x6 - 4 pcs.
G
H
A
A
A
A
A
B
B
D
D
F
I
b. remove screws M3x10 - 1 pcs.
I
J
6. Attention - Jump is set on slave part.
