Philips MG1100 - General description (Fig. 2); Preparing for use; Placing the batteries

General description (Fig. 2)
1 Precision trimming head
2 Handle
3 On/off slide
4 Locking indicator
5 ’Locked’ indication
6 ’Unlocked’ indication
7 Battery compartment cover
8 Precision shaving head
9 Long trimming comb (L)
10 Medium trimming comb (M)
11 Short trimming comb (S)
12 Cleaning brush
13 Disposable AA alkaline battery
Preparing for use
Placing the batteries
1 To remove the battery compartment cover, turn it clockwise until
the locking indicator points to the ‘unlocked’ indication.
2 Pull the battery compartment cover off the handle.
3 Put the battery in the battery compartment.
Make sure the + and - poles of the battery point in the right direction.
Note: The appliance runs on one R6 AA 1.5-volt battery (included). Preferably
use Philips alkaline batteries. A new AA alkaline battery has an operating time
of up to 2 hours.
ENGLISH 5
