Philips S3000 - Page 21

21
English
4
Remove two screws and then remove the hair
chamber from the shaver.
5
Lift out the front panel.
8×
6
Bend the eight snap hooks aside and remove the
cover of the power unit.
7
Lift out the two parts of the power unit.
1
2
2×
8
Break the battery tags with a pair of cutting pliers.
9
Remove the rechargeable battery.
