Issue date 2012-07-31
Version: 5.0.7
12 NC: 9082 100 02661
EAN: 87 10895 80711 1
© 2012 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
Specifications
SBCHC8430/00
Wireless hi-fi headphones
FM transmission
Highlights
3-way adjustable ear shells
Enjoy a comfortable fit and experience better bass
performance thanks to the three-way adjustable ear
shells that fit naturally around your ears.
Lightweight design
The durable, lightweight quality materials of these
Philips headphones enhance comfort for extended
wearing.
Automatic Level Control (ALC)
This smart electronic circuit ensures that the audio
input level is automatically adjusted to the right level,
preventing distortion and preserving your listening
enjoyment.
32 mm speaker driver
The 32 mm speaker driver is a compact yet powerful
element for delivering non-distorted sound with any
given input power.
FM Wireless transmission
With high frequency FM wireless transmission,
which can even pass through walls, you can even
listen to your music when you're in another room.
2 transmission channels
With a choice of two transmission channels your
listening pleasure is protected because you can easily
switch to the one with the best reception.
Battery included
No need to buy batteries to get started. Just drop
the batteries in and go!
Sound
• Acoustic system: closed
• Frequency response: 10 - 22 000 Hz
• Magnet type: Ferrite
• Sensitivity: 100 dB
• Speaker diameter: 32 mm
Tuner/Reception/Transmission
• Channel separation: >30 dB
• Pilot tone frequency: 19
• Effective range: 100 m
• Carrier frequency range: 863.0 - 865.0 MHz
• Modulation: FM
• Number of channel: 2
Convenience
• Automatic power off
• Low battery indicator
•Double PLL
• Operating time: +/- 15 hours
Power
• Power supply headphone: 2 x 1.5 V AAA
• Power supply transmitter: AC/DC adapter 12V/
20
0mA
Outer Carton
• Gross weight: 6.03 kg
•Outer carton (L x W x H): 44.9 x 34.5 x 32.9 cm
• Nett weight: 3.612 kg
• Tare weight: 2.418 kg
Packaging dimensions
• Packaging dimensions (W x H x D):
21.5 x 30.9 x 10.6 cm
• Gross weight: .867 kg
• Nett weight: .602 kg
• Tare weight: .265 kg
•
