Philips indoor luminaires8.16
Maxos
Light-line systems
Maxostrapezereectorsandoptics
The sturdy trapeze reectors for TL5 and TL-D are designed primarily
for applications in industry, supermarkets and shops. They are made of
steel with a white or silver outer nish. The reectors are optimized
for electrical units holding 1 or 2 TL5/TL-D lamps and provide an
excellent light output ratio.
There are basic trapeze reectors without an additional mirror inlay
and trapeze reectors with dedicated aluminum mirror inlays. These
are designed for wide-beam, narrow-beam and asymmetrical wall-
washing light distributions. Moreover, perforated and slotted trapeze
reectors (without mirror inlays) can be ordered for design reasons or
to create an indirect uplighting effect. For glare reduction, the trapeze
reector can be equipped with a steel louver.
Emergency lighting, for TL-D only
If emergency lighting by means of separately connected orientation
light units (E27-sockets) is required, special trapeze reectors with a
bigger cut-off must be used. The length of this reector corresponds
to that of the 58 W trunking length. A 36 W electrical unit plus the
orientation light unit will ll this length.
Maxos TL5
Trapeze reectors and optics
Type 4MX692 (TL5 reector)
4MX693 (TL5 louver/optic)
Suitable electrical unit For 1- and 2 TL5 49, 54 and 80 W versions
Material and light
distribution
Reector:
Steel, trapeze (T)
Steel, trapeze (T) with high gloss aluminum
mirror, medium beam (-MB)
Steel, trapeze (T) with high gloss aluminum
mirror, narrow beam (-NB)
Reector option:
Slotted, direct/indirect (T-S-D/I) or perforated
(T-P)
Louver:
Steel lamellae, white (L-T WH)
Installation Click-in xation on electrical unit
Accessory Trapeze reector end caps (9MX056 EP1-T WH/
SI)
Remarks Reectors and optics are suitable for 1- and 2-
lamp versions
Main applications Retail and general industry
Maxos TL-D
Trapeze reectors and optics
Type 4MX092 (TL-D reector)
4MX093 (TL-D louver/optic)
Suitable electrical unit For 1 and 2 TL-D 36 and 58 W versions
Material and light
distribution
Reector:
Steel, trapeze (T)
Steel, trapeze (T), with high gloss aluminum
mirror, wide beam (-WB)
Steel, trapeze (T), with high gloss aluminum
mirror, narrow beam (-NB)
Steel, trapeze (T), with high gloss aluminum
mirror, asymmetrical half reector (-A)*
Steel, trapeze (T), with high gloss aluminum
mirror, asymmetrical wallwasher (TI-A)*
Reector option:
Slotted, direct/indirect (T-S-D/I) or perforated
(T-P)
Optic and louver:
Steel lamellae, white (L-T WH) or silver (L-T SI)
Installation Click-in xation on electrical unit
Accessory Trapeze reector end caps 1 and 2-lamp version
(9MX056 EP1-T WH/SI, 9MX056 EP2-T WH/SI)
Remarks * For 1-lamp version only
Dedicated reectors for 1- and 2-lamp TL-D
versions
Main applications Retail and general industry
Where relevant, for detailed descriptions of Lighting Controls we refer you to chapter 11, and descriptions for e.g. optics/optical covers, lamps data, photometrical diagrams, etc. to the respective sections in chapter 12.
