17
4. USAGE AND OPERATION
IN
ON
OFF
OUT
TEMP
SET
℃
MIN
2）Display function
Timer on It is showed when the unit sets the timer on
Symbol
Meaning
Function
Cooling It is showed when the unit in cooling mode.
Heating
It is showed when the unit in heating mode and flashed
in defrosting.
Electric-
heating
It is showed when the unit in electric-heating mode.
(Swimming pool unit without this display）
Timer off
It is showed when the unit sets the timer off
Inlet water
It is showed when the main display area gives the inlet
water temperature.(measured value)
Outlet water
It is showed when the AUX display area gives the outlet
water temperature.(measured value)
Parameter
setting
It is showed when the parameter can be setted.
Temperature
It is showed when the main/ AUX display area gives
temperature
Centigrade
It is showed when the main/AUX display area
gives centigrade value
Minute
It is showed when the main/ AUX display area gives minute
value
IN OUT
IN OUT
ROOM
ROOM
