FL SWITCH 2000 / FL NAT 2000
90 / 226
PHOENIX CONTACT 108997_en_04
Signal contact
Output name Digital output
Control voltage range 9 VDC ... 57 VDC
Current carrying capacity typ. 100 mA
max. 0.7 A (1 minute)
Connection data
Connection method Push-in spring connection
Note on the connection method Use only copper connecting cables providing the permitted
temperature range (-40°C ... 75°C).
pluggable Yes
Conductor cross section solid min. 0.25 mm²
Conductor cross section solid max. 1.5 mm²
Conductor cross section flexible min. 0.25 mm²
Conductor cross section flexible max. 1.5 mm²
Conductor cross section AWG min. 24
Conductor cross section AWG max. 16
Stripping length 9 mm
Interface: Ethernet (RJ45)
Number of interfaces 6
Connection method RJ45
Note on the connection method Auto negotiation and autocrossing
Transmission physics Copper
Transmission speed 10/100 Mbps
Transmission length 100 m (per segment)
Interface: Ethernet FO
Number of interfaces 2
Connection method SC
Transmission physics Single-mode fiberglass
Transmission speed 100 Mbps (full duplex)
Transmission length 36000 m (fiberglass with F-G 9/125 0.36 dB/km)
Transmission length 32000 m (fiberglass with F-G 9/125 0.4 dB/km)
Transmission length 26000 m (fiberglass with F-G 9/125 0.5 dB/km)
Wavelength 1300 nm
Supply voltage
Supply voltage 24 VDC (redundant)
Residual ripple 3.6 V
PP
(within the permitted voltage range)
Supply voltage range 9 VDC ... 57 VDC
Typical current consumption 235 mA (at U
S
= 24VDC and 25°C ambient temperature)
