4.12 Transferring a project to the controller
To transfer the project to the controller, proceed as follows:
• Double-click on the controller node in the “PLANT” area.
The controller editor group opens.
• Select the “Cockpit” editor.
• Click on the button (“Write project to controller and start execution. (F5)”).
The project is compiled, transferred to the controller, and executed.
If startup was carried out successfully, the following appears on the RFC 4072S display:
Figure 4-38 Controller in the RUN state, PROFINET controller in the ACTIVE state
If an installation error prevents the system from starting up, a corresponding error message
appears on the display and in PLCnext Engineer.
User authentication
If necessary, refer to the information about user authentication on page 98.
• If necessary, enter the user name and password in the dialog that opens.
The iSPNS 3000 is in the FAIL state, as no safety programming has been performed in
the example project.
