RFC 4072S
182 / 272
PHOENIX CONTACT 108580_en_02
The SPNS_V2_PROFISAFE_DIAG system variable uses the PROFISAFE_DIAG_OUT
structure to provide further information about the iSPNS 3000.
Table 8-5 SPNS_V2_PROFISAFE_DIAG system variable and elements of the PROFISAFE_DIAG_OUT structure
System variable/elements Ty p e Meaning
SPNS_V2_PROFISAFE_DIAG PROFIS-
AFE_DI-
AG_OUT
The structure provides PROFIsafe diagnostic information of the
individual configured F-Devices.
MAX_PS_RECORDS UINT Maximum number of F-Devices to be configured
USED_PS_RECORDS UINT Configured number of F-Devices
PS_RECORDS
[1] … [300] PROFIsafe records 1 … 300
CODE_NAME DWORD –
DIAG_BIT_FIELD DWORD –
SRT_MIN UINT Minimum roundtrip time between F-Host and F-Device
SRT_MAX UINT Maximum roundtrip time between F-Host and F-Device
SRT_CUR UINT Current roundtrip time between F-Host and F-Device
FWD_TIME UINT Watchdog time
VALID_REG UINT –
NODE_ID UDINT Node ID
Reserved UINT Reserved
PS_GLOBAL_RECORD DWORD –
