PN Device
(PROFINET device)
Table 2-6 Status information: PN Device (PROFINET device)
Indicator Color Meaning
Green No connector is inserted into the LAN3 PROFINET device inter-
face (link not present).
BF is red.
Green A connector is inserted into the LAN3 PROFINET device inter-
face (link is present).
No application relationship established.
BF flashing red.
Green An application relationship is established between the higher-
level PROFINET controller and the RFC 4072S
(PROFINETdevice).
Red Internal firmware error of the RFC 4072S (PROFINET device).
