Phoenix Contact RFC 4072S User Manual

Description of the RFC 4072S
108580_en_02 PHOENIX CONTACT 63 / 272
Figure 2-30 Overload range with fall-back characteristic curve
Figure 2-31 Overload range without fall-back characteristic curve
24
U
OUT
[V]
I
OUT
[A]
6219B070
 1.1 x I
N
 2.4 x I
N
I
N
Overload range
with fall-back
characteristic curve
6219B071
24
U
OUT
[ ]
V
I
OUT
[ ]
A
I
N
1.5 x I 
N
Overload range
without fall-back
characteristic curve
