RFC 4072S
78 / 272
PHOENIX CONTACT 108580_en_02
3. If present, disconnect the Ethernet connection.
Figure 3-8 Disconnecting the Ethernet connection
4. Remove the RFC to be replaced from the DIN rail.
Figure 3-9 Removing the RFC from the DIN rail
107586A007
B
A
C
D
g
108580A009
