Phonak Audeo B50-R - Mini Charger RIC; Mini Charger RIC Diagram

10 11
Mini Charger RIC
Hearing aid charging inserts
with left/right indicators
micro-USB connection
to external power supply
Indicator light for power
Charger Case RIC with optional Power Pack
Charger Case RIC
Indicator light for power
micro-USB connection
to external power supply
micro-USB connection to external power supply
Power Pack
Indicator light for battery status
and external power
Battery check button
Power Pack lock and release
